Features and Benefits
- More smaller filter systemand fewer elements to change out
- High flow rates per filter cartridge – up to 76m³/hr
- Inner core with high mechanical strength and netting of outer cage
- High flow rate capacity reduce number of cartridges required and allows for smaller housings
- High dirt holding capacity and longer service life than traditional cartridges
- Less cartridge change out to save the labor cost
- High surface area pleated design provides lower pressure drop and longer service life
- PP(Polypropylene)materials in compliance with FDA regulations
- Wide chemical compatibility for different applications
Applications
- Prefiltration for RO and Seawater Desalination
- Power Generation Condensate treatment
- Food & Beverage
- Petrochemicals and Refineries
- Paints and coatings
Technical Specifications
| Size | Length | 40″(1016mm) | |
| OD | 6inch(152mm) | ||
| Filtration area | 5.5㎡@40inch | ||
| Materials | Filter Media | PP(Polypropylene) | |
| End caps/ Outer cage | PP(Polypropylene) | ||
| O-ring seal | EPDM / Buna-N / Silicone / Viton | ||
| Flow rate | Size | Max flow rate | Design Flow rate |
| 40inch | 76m³/hr | 40m³/hr | |
| Operation conditions | Max. Temperature | ~80 ℃ | |
| Recommended DP for change-out | 2.1-2.4bar | ||
