Features and Benefits
- Mainly designed for power plant condensed water filtration
•Pleated design increased the filtration area and with high dirt holding capacity
•Wide chemical compatibility for different application
•Backwash design increase the life time
•Less damage from iron and copper to the boiler and turbine of condensed system
Applications
- Power plant Condensate Polishing system
Technical Specifications
| Size | Length | 30-80inch |
| Inner Diameter | 36.7mm | |
| Outer Diameter | 68mm | |
| Filtration area | 4.06㎡ | |
| Materials | Filtration Media | PP(Polypropylene) |
| Inner core | PP(Polypropylene) | |
| Out cage | PP(Polypropylene) | |
| Endcaps | PP(Polypropylene) and SS316 | |
| Operation conditions | Max. Temperature | ≤70 ℃ |
| Max Operating DP | 0.4 MPA @ 21℃
0.24 MPA@ 70℃ |
|
| Recommended Flow Rate | 15m³/h/10inch | |
| Recommended backwash water flow | 0.45-0.68m³/h | |
| Recommended backwash air flow | 3.4-5m³/h |
